Orbea Optima E50 20mph
$2,700.00 - $2,899.00
Details
Optima is a seemingly "normal" bicycle, but both the architecture and the ergonomics of the new Optima are innovative. It's a bike designed to be used as an electric bicycle from the conceptual design phase. This has meant revamping the product to the point that even its architecture changed.
| Small | Medium | Large | |
|---|---|---|---|
| 1 1 - SEAT TUBE (C-T) | 405 | 450 | 500 |
| 2 2 - TOP TUBE (EFF) | 625 | 648 | 693 |
| 3 3 - HEAD TUBE | 190 | 240 | 270 |
| 4 4 - CHAINSTAY | 510 | 510 | 510 |
| 5 5 - BB HEIGHT | 272,5 | 272,5 | 272,5 |
| 6 6 - BB DROP | 95 | 95 | 95 |
| 7 7 - WHEELBASE | 1163 | 1187 | 1233 |
| 8 8 - HEAD ANGLE | 70° | 70° | 70° |
| 9 9 - SEAT ANGLE | 72° | 72° | 72° |
| 10 11 - REACH | 397 | 405 | 440 |
| 11 12 - STACK | 662 | 709 | 737 |
| 12 13 - FORK LENGTH | 433 | 433 | 433 |
| 13 RAKE | 55 | 55 | 55 |
| Frame Size | Rider Height (in) |
|---|---|
| Small | 59.1"-65.0" |
| Medium | 65.0"-70.9" |
| Large | 70.9"-78.7" |
Due to supply-chain issues, Specs are subject to change without notice.
Specs
| Frame | Orbea Optima Hydroformed Alloy, Ebikemotion X35 internal battery |
|---|---|
| Fork | Optima 400mm Alloy Post mount |
| Wheels | Alloy, Tubeless, 700c, 21c, 32H |
| Axles | Safety Lock |
| Tires | Kenda 1172 700x50c |
| Crankset | Orbea, Alloy, 42t |
| Shifters | Shimano SL-M315 |
| Rear Derailleur | Shimano Tourney TX800 |
| Cassette/Freewheel | Sun Race CSM66 11-34t 8-Speed |
| Chain | KMC X8 |
| Brakes | Shimano TX805 Mechanical Disc |
| Brake Levers | Shimano Alivio BL-T4010 |
| Handlebars | Orbea City Riser Alu 640mm |
| Stem | Orbea TDS-D617 |
| Headset | VP-Z104PD 1-1/8" Semi-Cartridge |
| Seatpost | Alloy, 31.6mm, Setback 0 |
| Saddle | Selle Royal Milo Plus DR |
| Pedals | VP-857 Black |
| Accessories & Extras | Remote: Mahle iWoc TRIO |
| Motor | Mahle motor hub X35 Plus |
| Battery | Mahle 36V/6.9A 248Wh ANT+ |
| Charger | Mahle X35 |
* Subject to change without notice.
Part Numbers
| Option | UPC | MPN |
|---|---|---|
| Blue (Gloss) / Small | 08434446232596 | N60317XX |
| Blue (Gloss) / Medium | 08434446232626 | N60318XX |
| Blue (Gloss) / Large | 08434446232657 | N60320XX |
| Metallic Dark Red (Gloss) / Small | 08434446232589 | N60317XW |
| Metallic Dark Red (Gloss) / Medium | 08434446232619 | N60318XW |
| Metallic Dark Red (Gloss) / Large | 08434446232640 | N60320XW |
| Metallic Night Black (Gloss) / Small | 08434446232572 | N60317XV |
| Metallic Night Black (Gloss) / Medium | 08434446232602 | N60318XV |
| Metallic Night Black (Gloss) / Large | 08434446232633 | N60320XV |
